Welcome to Part 2 of my series Working with Terraform on Oracle Cloud Infrastructure (OCI)

If you need a refresher, visit Part 1

In Part 1, we have done the following:

Installed Terraform
Created .tf scripts
Executed the workflows, Initialize > Plan > Apply
Authenticated our OCI tenant with the Terraform provider scripts

In Part 2, let's look at how we can provision compartments & provision compute & network resources within these compartments.

In Part 1, we created the following .tf file which allowed Terraform to authenticate with our OCI tenant.


In Part 2, we will first need to create a compartment to store our resources that we'll be creating later. To do this, we will need 2 .tf files in our working folder.


Creating the Working Directory

Let's begin with creating the working directory to store our files in it. Once, the files are defined, we'll initialize Terraform & put it to work from this directory.

Create a directory called 'tf-compartment' under your root directory.

$ mkdir tf-compartment

Copy the provider.tf file from the tf-provider directory to this directory (tf-compartment). Once you have that in place, let's create the compartment.tf file & define the parameters. Add the following code in your file.

resource "oci_identity_compartment" "tf-compartment" {
    compartment_id = "<tenancy-ocid>"
    description = "Compartment for Terraform resources."
    name = "<your-compartment-name>"
}

Defining Policies on OCI

Let's add a policy on our OCI tenant.

Navigate to Identity & Security > Policies
Choose a Compartment if you have one or select the root compartment for now
Click Create Policy & click Show manual editor
Paste the following policy & click Create

allow group <the-group-your-username-belongs> to manage compartments in tenancy

Creating the Compartment

Initialize

First, let's initialize Terraform within our working directory, tf-compartment

$ terraform init

You'll get the following output

terraform init.PNG

Plan

Once, we've initialized Terraform, let's plan our deployment.

$ terraform plan

You'll get an output like this:

terraform plan.PNG

Apply

Once we're good with our plan, let's proceed with creating the compartment by issuing the following command

$ terraform apply

You'll get an output like these:

terraform apply1.PNG

terraform apply2.PNG Now, let's verify the creation in our OCI tenant

terraform compartment oci.PNG

There you go. Our compartment has been successfully created on OCI

Provisioning a Compute Instance in an Existing VCN

Now, let's attempt to provision a compute instance in our compartment, vickterraform2. This compute instance will be provisioned into an existing Virtual Cloud Network, vickvcn1, in the OCI tenant

Generating SSH Keys

I'll be generating SSH keys which will be used to connect to the compute instance which I'll be creating later

$ ssh-keygen -t rsa -N "" -b 2048 -C <your-ssh-key-name> -f <your-ssh-key-name>

This will generate a public & private key pair for you. You would get something like this

ssh key gen.PNG

Gather Important Information

Before we begin creating the scripts, let's gather the important information that we'll be using in our scripts

Compartment Name
Compartment ID
Subnet ID
Source ID
Shape
Path of your SSH public key
Path of your SSH private key

Getting the Source ID

The Source ID refers to the ID of the source image of your compute & this depends on what image (Ubuntu, CentOS, Oracle Linux, Windows, etc.) you would like to provision

To get the Source ID:

Identify your region. Mine is us-ashburn-1
Refer here: Image Release Notes
For this deployment, I'll be using an Ubuntu 20.04 image & this is my Source ID to the image according to my region: ocid1.image.oc1.iad.aaaaaaaaos5ofuq26nipxcybznimsjnhyw3jf7mrq2r3kgpsf6zqbtqei25q

Getting the Shape

The shape refers to the size of the compute instance which defines the allocation of CPUs & memory

To get the shape:

Refer here: VM Standard Shapes
I'll be using a VM.Standard2.1 shape

Add Policies to OCI

Let's add the following policy in Identity & Security > Identity > Policies under your compartment

allow group <the-group-your-username-belongs> to manage all-resources in compartment <your-compartment-name>

Creating the Scripts

Let's setup a new working directory for this called 'tf-compute'

$ mkdir tf-compute

Copy your 'provider.tf' file into this directory

$ cp ../tf-provider/provider.tf .

Let's also copy the 'availability-domains.tf' file which we created in the initial setup into this directory

cp ../tf-provider/availability-domains.tf .

The 'availability-domains.tf' has the following code

data "oci_identity_availability_domains" "ads" {
  compartment_id = "<tenancy-ocid>"
}

Let's also create an 'outputs.tf' file in the 'tf-compute' directory

output "name-of-first-availability-domain" {
  value = data.oci_identity_availability_domains.ads.availability_domains[0].name
}

Now, we have the following files in our tf-compute directory

provider.tf
availability-domains.tf
outputs.tf

Let's initialize > plan > apply our Terraform scripts

$ terraform init
$ terraform plan
$ terraform apply

Once you've hit the terraform apply, you'll be provided with an output of your availability domain

terraform apply3.PNG

Declare the Compute Resource

Now that we're ready to provision the compute instance, let's create a 'compute.tf' file & add the following code into the file

resource "oci_core_instance" "ubuntu_instance" {
    # Required
    availability_domain = data.oci_identity_availability_domains.ads.availability_domains[0].name
    compartment_id = "<compartment-ocid>"
    shape = "VM.Standard2.1"
    source_details {
        source_id = "<source-ocid>"
        source_type = "image"
    }

    # Optional
    display_name = "<your-ubuntu-instance-name>"
    create_vnic_details {
        assign_public_ip = true
        subnet_id = "<subnet-ocid>"
    }
    metadata = {
        ssh_authorized_keys = file("<ssh-public-key-path>")
    }
    preserve_boot_volume = false
}

This is my completed file

compute tf.PNG

Now, let's run our scripts

$ terraform init
$ terraform plan
$ terraform apply

And, we have successfully created our Ubuntu server via Terraform. Also, let's verify this on the OCI console

create instance.PNG

vick ubuntu.PNG

Let's also try connecting to this server

$ ssh -i <ssh-private-key-path> ubuntu@<your-public-ip-address>

And there you go. We've successfully accessed the Ubuntu server

vick ubuntu1.PNG

Now that I've tested the deployment & it's working, I will proceed to delete this compute instance

$ terraform destroy

Simultaneously on the console, the instance is getting terminated

instance terminating.PNG

Once the instance is completely terminated, you will get the following output

instance terminated.PNG

Creating a New Virtual Cloud Network (VCN)

In this section, I will demonstrate the creation of a new Virtual Cloud Network (VCN) & its associated components such as subnets, gateways, security lists & more

creating a vcn.png

Gather Important Information

Before we begin, let's gather the important information that we'll be using in our scripts

Compartment Name
Compartment ID
Region

Create a Working Directory

Let's create a new working directory for this demo & let's name it 'tf-vcn'

$ mkdir tf-vcn

Copy the 'provider-tf' file from the 'tf-provider' directory into this directory

cp ../tf-provider/provider.tf .

Declaring the VCN Configuration

Now, let's create a file called 'vcn-module.tf' & insert the following code into it

# Source from https://registry.terraform.io/modules/oracle-terraform-modules/vcn/oci/
module "vcn"{
  source  = "oracle-terraform-modules/vcn/oci"
  version = "3.1.0"
  # insert the 5 required variables here

  # Required Inputs
  compartment_id = "<compartment-ocid>"
  region = "<region-identifier>"

  internet_gateway_route_rules = null
  local_peering_gateways = null
  nat_gateway_route_rules = null

  # Optional Inputs
  vcn_name = "vcn-module"
  vcn_dns_label = "vcnmodule"
  vcn_cidrs = ["10.0.0.0/16"]

  create_internet_gateway = true
  create_nat_gateway = true
  create_service_gateway = true
}

Here's a sample of my code

vcn module.PNG

Let's also create an 'outputs.tf' file & insert the following code to get the information of the VCN once we run the scripts

# Outputs for the vcn module

output "vcn_id" {
  description = "OCID of the VCN that is created"
  value = module.vcn.vcn_id
}
output "id-for-route-table-that-includes-the-internet-gateway" {
  description = "OCID of the internet-route table. This route table has an internet gateway to be used for public subnets"
  value = module.vcn.ig_route_id
}
output "nat-gateway-id" {
  description = "OCID for NAT gateway"
  value = module.vcn.nat_gateway_id
}
output "id-for-for-route-table-that-includes-the-nat-gateway" {
  description = "OCID of the nat-route table - This route table has a nat gateway to be used for private subnets. This route table also has a service gateway."
  value = module.vcn.nat_route_id
}

Creating the VCN

Now that we have the required scripts configured, let's create the VCN

$ terraform init

$ terraform plan

$ terraform apply

And there you go. We've successfully created the VCN & the gateways

vcn created.PNG

Let's also verify this on the OCI console

vcn oci console.PNG Notice that we don't have any subnets in our VCN yet. We'll be creating this later

Customizing the VCN

Before we jump on to create subnets, I would like to define security lists for my subnets

Creating a Security List for the Private Subnet

Let's create a file called 'private-security-list.tf' & add the following code into it

# Source from https://registry.terraform.io/providers/hashicorp/oci/latest/docs/resources/core_security_list

resource "oci_core_security_list" "private-security-list"{

# Required
  compartment_id = "<compartment-ocid>"
  vcn_id = module.vcn.vcn_id

# Optional
  display_name = "security-list-for-private-subnet"
}

Let's also add an egress rule to this security list by adding the following code into our file


  egress_security_rules {
      stateless = false
      destination = "0.0.0.0/0"
      destination_type = "CIDR_BLOCK"
      protocol = "all"
  }

Here's a sample of my code SL private subnet.PNG

Also, let's add the following code into the 'outputs.tf' file

# Outputs for private security list

output "private-security-list-name" {
  value = oci_core_security_list.private-security-list.display_name
}
output "private-security-list-OCID" {
  value = oci_core_security_list.private-security-list.id
}

Once we have created our scripts, let's run the creation of the security list for our private subnet

$ terraform init

$ terraform plan

$ terraform apply

And we've successfully created our security list along with its egress rule

SL created.PNG

Now that's successful, let's also create ingress rules for our security lists. In the 'private-security-list.tf', let's add the following code into it

ingress_security_rules {
      stateless = false
      source = "10.0.0.0/16"
      source_type = "CIDR_BLOCK"
      # Get protocol numbers from https://www.iana.org/assignments/protocol-numbers/protocol-numbers.xhtml TCP is 6
      protocol = "6"
      tcp_options {
          min = 22
          max = 22
      }
    }
  ingress_security_rules {
      stateless = false
      source = "0.0.0.0/0"
      source_type = "CIDR_BLOCK"
      # Get protocol numbers from https://www.iana.org/assignments/protocol-numbers/protocol-numbers.xhtml ICMP is 1
      protocol = "1"

      # For ICMP type and code see: https://www.iana.org/assignments/icmp-parameters/icmp-parameters.xhtml
      icmp_options {
        type = 3
        code = 4
      }
    }

  ingress_security_rules {
      stateless = false
      source = "10.0.0.0/16"
      source_type = "CIDR_BLOCK"
      # Get protocol numbers from https://www.iana.org/assignments/protocol-numbers/protocol-numbers.xhtml ICMP is 1
      protocol = "1"

      # For ICMP type and code see: https://www.iana.org/assignments/icmp-parameters/icmp-parameters.xhtml
      icmp_options {
        type = 3
      }
    }

Once again, let's run our scripts

$ terraform init

$ terraform plan

$ terraform apply

Now that it has successfully ran, we are able to see the ingress & egress rules created for the security list for the private subnet

SL Ingress.PNG

SL Egress.PNG

Creating a Security List for the Public Subnet

Now, let's replicate the above operations for our public subnet. Let's copy the file 'private-security-list.tf' to a new file called 'public-security-list.tf' & let's modify the parameters

$ cp private-security-list.tf public-security-list.tf

Let's change the code private-security-list in the resource block to public-security-list & change the display_name from security-list-for-private-subnet to security-list-for-public-subnet

We'll maintain the egress rule. However, for the ingress rule let's change the source = "10.0.0.0/16" to source = "0.0.0.0/0"

Your code should look like this


ingress_security_rules {
      stateless = false
      source = "0.0.0.0/0"
      source_type = "CIDR_BLOCK"
      # Get protocol numbers from https://www.iana.org/assignments/protocol-numbers/protocol-numbers.xhtml TCP is 6
      protocol = "6"
      tcp_options {
          min = 22
          max = 22
      }
    }
  ingress_security_rules {
      stateless = false
      source = "0.0.0.0/0"
      source_type = "CIDR_BLOCK"
      # Get protocol numbers from https://www.iana.org/assignments/protocol-numbers/protocol-numbers.xhtml ICMP is 1
      protocol = "1"

      # For ICMP type and code see: https://www.iana.org/assignments/icmp-parameters/icmp-parameters.xhtml
      icmp_options {
        type = 3
        code = 4
      }
    }

  ingress_security_rules {
      stateless = false
      source = "10.0.0.0/16"
      source_type = "CIDR_BLOCK"
      # Get protocol numbers from https://www.iana.org/assignments/protocol-numbers/protocol-numbers.xhtml ICMP is 1
      protocol = "1"

      # For ICMP type and code see: https://www.iana.org/assignments/icmp-parameters/icmp-parameters.xhtml
      icmp_options {
        type = 3
      }
    }

Let's also add the following code to the 'outputs.tf' file


# Outputs for public security list

output "public-security-list-name" {
  value = oci_core_security_list.public-security-list.display_name
}
output "public-security-list-OCID" {
  value = oci_core_security_list.public-security-list.id
}

Now, let's run our scripts

$ terraform init

$ terraform plan

$ terraform apply

Now, we are able to see on the console that the security list & its ingress & egress rules have been created

SL public ingress.PNG

SL public egress.PNG

Creating the Private Subnet

We are not done yet as we have not created the subnets for our VCN. Let's start by creating a private subnet

Let's create a file called 'private-subnet.tf' & add the following code to it

# Source from https://registry.terraform.io/providers/hashicorp/oci/latest/docs/resources/core_subnet

resource "oci_core_subnet" "vcn-private-subnet"{

  # Required
  compartment_id = "<compartment-ocid>"
  vcn_id = module.vcn.vcn_id
  cidr_block = "10.0.1.0/24"

  # Optional
  # Caution: For the route table id, use module.vcn.nat_route_id.
  # Do not use module.vcn.nat_gateway_id, because it is the OCID for the gateway and not the route table.
  route_table_id = module.vcn.nat_route_id
  security_list_ids = [oci_core_security_list.private-security-list.id]
  display_name = "private-subnet"
}

Let's also add the following to the 'outputs.tf' file


# Outputs for private subnet

output "private-subnet-name" {
  value = oci_core_subnet.vcn-private-subnet.display_name
}
output "private-subnet-OCID" {
  value = oci_core_subnet.vcn-private-subnet.id
}

Now, let's run our scripts

$ terraform init

$ terraform plan

$ terraform apply

And there you go. We've created our private subnet with a CIDR block of 10.0.1.0/24

Creating the Public Subnet

Let's do the above for the public subnet. To begin, let's create a file called 'public-subnet.tf' & add the following code

# Source from https://registry.terraform.io/providers/hashicorp/oci/latest/docs/resources/core_subnet

resource "oci_core_subnet" "vcn-public-subnet"{

  # Required
  compartment_id = "<compartment-ocid>"
  vcn_id = module.vcn.vcn_id
  cidr_block = "10.0.0.0/24"

  # Optional
  route_table_id = module.vcn.ig_route_id
  security_list_ids = [oci_core_security_list.public-security-list.id]
  display_name = "public-subnet"
}

And, add the following code to the 'outputs.tf' file


# Outputs for public subnet

output "public-subnet-name" {
  value = oci_core_subnet.vcn-public-subnet.display_name
}
output "public-subnet-OCID" {
  value = oci_core_subnet.vcn-public-subnet.id
}

Now, let's run our scripts

$ terraform init

$ terraform plan

$ terraform apply

And now, we have successfully created our public subnet with a CIDR block of 10.0.0.0/24

Summary

This sums Part 2 of this blog. In Part 2, we've created the following

A compartment
A Ubuntu 20.04 compute instance
A Virtual Cloud Network (VCN)
Security List for Private Subnet with Ingress & Egress Rules
Security List for Public Subnet with Ingress & Egress Rules
A Private Subnet
A Public Subnet

In Part 3, I will be covering how we can incorporate the above in a single Terraform script & provision an infrastructure on OCI. Stay tuned.

Deploying Workloads on Oracle Cloud Infrastructure (OCI) via Terraform - PART 2

Comments

Working with Terraform on Oracle Cloud Infrastructure (OCI)

Deploying Workloads on Oracle Cloud Infrastructure (OCI) via Terraform - PART 1

More from this blog

Deploying Workloads on Oracle Cloud Infrastructure (OCI) via Terraform - PART 1

Securing Your Database with Oracle Data Safe

Data Ownership

Creating the Working Directory

Defining Policies on OCI

Creating the Compartment

Initialize

Plan

Apply

Provisioning a Compute Instance in an Existing VCN

Generating SSH Keys

Gather Important Information

Getting the Source ID

Getting the Shape

Add Policies to OCI

Creating the Scripts

Declare the Compute Resource

Creating a New Virtual Cloud Network (VCN)

Gather Important Information

Create a Working Directory

Declaring the VCN Configuration

Creating the VCN

Customizing the VCN

Creating a Security List for the Private Subnet

Creating a Security List for the Public Subnet

Creating the Private Subnet

Creating the Public Subnet

Summary

Command Palette

Comments

Working with Terraform on Oracle Cloud Infrastructure (OCI)

Deploying Workloads on Oracle Cloud Infrastructure (OCI) via Terraform - PART 1

More from this blog

Creating the Working Directory

Defining Policies on OCI

Creating the Compartment

Initialize

Plan

Apply

Provisioning a Compute Instance in an Existing VCN

Generating SSH Keys

Gather Important Information

Getting the Source ID

Getting the Shape

Add Policies to OCI

Creating the Scripts

Declare the Compute Resource

Creating a New Virtual Cloud Network (VCN)

Gather Important Information

Create a Working Directory

Declaring the VCN Configuration

Creating the VCN

Customizing the VCN

Creating a Security List for the Private Subnet

Creating a Security List for the Public Subnet

Creating the Private Subnet

Creating the Public Subnet

Summary
